PET Bottle Blowing Compressor

Medium and high pressure air compressor for blow molding of plastic bottles
PET Bottle Blowing Compressor
PET Bottle Blowing Compressor PET Bottle Blowing Compressor

Xinran PET air compressor is a crucial component in blow molding machine setups, designed to convert mechanical energy from a prime mover (typically an electric motor) into pneumatic pressure energy. It specifically generates the compressed air required for operating bottle blowing machines. After extensive operational testing across various conditions, PET air compressor has proven to offer higher efficiency, stronger reliability with capability of continuous 24-hour operation without shutdown, longer lifespan, lower noise levels, minimal vibration, lower discharge temperatures, and reduced oil consumption.

Request a Quote
  • Free air delivery

    0.6-6m³/min

  • Power

    7-6×11kW

  • Discharge pressure

    3.0-8.0MPa

Applications

Xinran bottle blowing compressors have been widely adopted by numerous beverage manufacturers due to their reliability and efficiency. Notable clients include Master Kong, Wahaha, Nongfu Spring, Uni-President, Dali Group, Coca-Cola, PepsiCo, Huiyuan Juice, Yeshu, Red Bull, Minute Maid, 7UP, Watsons, Wanglaoji, Lulu, Nestlé, Suntory, Wellcome, Bright Dairy, Yili, and Mengniu.

Technical Data
Model Free Air Delivery (m³/min) Discharge pressure (Mpa) Power (kW) Speed (rpm) Dimensions (L×W×H) (mm) Weight (kg)
VH-0.7/30-SB 0.7 3 7.5 680 1240×630×780 310
WH-1.0/30-SB 1 3 11 600 1470×780×885 430
WH-1.2/30-SB 1.2 3 15 760 1470×780×885 450
WH-1.5/30-SB 1.5 3 18.5 790 1530×765×1105 520
PWH-1.0/40-SB 1 4 11 790 1400×840×840 470
VH-0.65/35 0.65 3.5 9 800 1800×630×1140 420
VH-0.7/30 0.7 3 7.5 680 1800×630×1140 410
WH-1.0/30 1 3 11 600 2005×795×1260 530
WH-1.1/35 1.1 3.5 11 605 2005×795×1260 550
WH-1.2/30 1.2 3 15 760 2005×795×1260 550
WH-1.3/35 1.3 3.5 18.5 680 1140×735×1450 520
WH-1.5/30 1.5 3 18.5 790 1140×735×1450 520
2-WH-2.0/30 2 3 2×11 600 2050×1570×980 1050
2-WH-2.2/35 2.2 3.5 2×15 605 1880×1180×1440 1080
2-WH-2.4/30 2.4 3 2×15 760 2050×1570×980 1080
2-WH-2.6/35 2.6 3.5 2×18.5 700 1880×1180×1440 1150
2-WH-3.0/30 3 3 2×18.5 790 1880×1180×1440 1150
3-WH-3.6/30 3.6 3 3×15 700 2350×1570×1880 1580
4-WH-5.0/35 5 3.5 4×18.5 680 2520×1920×1540 2400
4-WH-6.0/30 6 3 4×18.5 790 2520×1920×1540 2400
WH-0.6/60 0.6 6 11 555 1420×830×840 320
VH-0.65/35 0.65 3.5 7.5 800 1250×760×800 475
WH-0.9/70 0.9 7 15 735 1420×830×840 467
WH-0.93/105 0.93 10.5 15 900 1100×815×1405 470
WH-0.94/98 0.94 9.8 15 900 1100×815×1405 470
WH-1.0/55 1 5.5 15 790 1420×830×840 470
WH-1.0/80 1 8 15 800 1420×830×840 467
WH-1.1/35 1.1 3.5 11 900 1420×830×840 475
WH-1.0/40 1 4 11 790 1420×830×840 475
WH-1.7/40 1.7 4 2 735 1140×710×1500 550
WH-1.9/40 1.9 4 25 860 1140×735×1650 550
2-WH-1.8/70 1.8 7 2×15 735 1880×1430×1000 1480
2-WH-2.0/55 2 5.5 2×15 790 1880×1430×1000 1480
2-WH-2.0/80 2 8 2×15 800 1950×1180×1440 1480
W-WH-2.2/35 2.2 3.5 2×11 800 1880×1430×1000 1500
4-WH-4.0/40 4 4 4×11 790 2020×1570×2000 2400
6-WH-6.0/40 6 4 6×11 790 3495×1565×2000 3600
